Server & NAS Cases for those who need HDDs

A list of popular NAS and Server cases with pictures and some specifications for your next NAS or Server build.

Server & NAS Cases for those who need HDDs
My server madness.

There are plenty of NAS & Server cases out there. Since I have changed my case 3 times now, I have done some research for myself and just put it out there for others.

My personal case study 😜 (pun intended):

  1. Fractal Design Node 804
  2. SilverStone DS380B
  3. Fractal Design Define 7

My general advice for building a NAS with some HDD storage: If you have the space, do not go into small form-factor builds.

  • They tend to be more expensive
  • They are generally louder
  • They are generally warmer
  • Building in them can be a pain

And as a reminder for motherboard sizing:

Camparison from ATX, Micro-ATX, Mini-ITX, Nano-ITX, Pico-ITX Motherboards
By VIA Gallery from Hsintien, Taiwan - VIA Mini-ITX Form Factor Comparison uploaded by Kozuch, CC BY 2.0, https://commons.wikimedia.org/w/index.php?curid=3928561

Anyway, here is the list of cases I had a look into.

Smal Form Factor (SFF) NAS cases

SilverStone DS380 / DS380B

The DS380B is a newer revision and has smaller capacitors on the backplane for the SATA/SAS ports. They were pretty big and could be knocked off easily. You can still manage that; just be a bit careful. That is about the difference, as far as I can tell.

  • Drive Bay:
    • 8 x 3.5" SAS/ SATA hot-swap (2.5” compatible)
      • These are external and easy to swap!
    • 4 x 2.5"
  • Motherboard: Mini-DTX, Mini-ITX
  • Power Supply: SFX PSU
  • Dimension:
    • 211mm (W)
    • 285mm (H)
    • 360mm (D)
    • 21.6 liters
  • Price: ~175 Euros (06.04.2025)

I owned this case at some point. It is okay. Back then, I needed the small form factor, and it was great for that. However, building in here is not fun at all! especially when you think of populating all 4 SSDs in the small SSD cage. Getting them out there is also a major pain.

Mods
